HTC 2 MHz Function Generator FG-2002

Product Description

• 5 Digit LED Display ( including 3 digits for voltage)

• Frequency And Amplitude Display Simultaneously

• Output Waveforms: Sine Wave, Square Wave And Triangle Wave

• Frequency Of Output Signal: 0.2Hz ~ 2MHz

• Duty Cycle Adjustable: 20% ~ 80%

• Width Of Output Signal Adjustable Continuously

• Amplitude Without Attenuation: 0.9V ~ 10V

• Amplitude with -20dB attenuation; 100mV ~ 1V

• Amplitude with -40dB attenuation: 10mV ~100mV

• Standard Accessories: Power Cord, Manual

Product Specification

Brand Name	HTC
Product Code	FG-2002
Product Type	Function Generator
Model No	HTC-W1
Power	AC 110/220V
Dimension	270(H) x 215(W) x 100(D)mm
Warranty	As Per Manufacturer Terms And Condition
