SKF Pillow Block Ball Bearing 20mm UCPA 204

Product Description

• Short base pillow block ball bearing unit with extended inner ring and set screw locking, Japanese Industrial Standards

• Short base pillow (plummer) block ball bearing units consist of an insert bearing mounted in a cast iron housing

• This variant has threaded holes for attachment bolts and is suitable for applications where the direction of rotation is constant or alternating

• It has an inner ring extended on both sides and is locked onto the shaft by tightening two set screws on the inner ring, making it easy to mount

• The units are compliant with Japanese Industrial Standards (JIS)

• Optimized for applications where space is limited

• Ready to mount

• Lubricated and sealed bearing

• Quick locking onto the shaft

• Extended inner ring for minimized shaft misalignment

• Warranty and support will be provided by vendor

• Note:*Actual product image may vary from that shown on the picture

Product Specification

Brand	SKF
Product Type	Ball Bearing
Product Model	UCPA 204
Shaft Diameter	20 mm
pillow Block Centre Height	30.2 mm
Housing Overall Width	34 mm
Centre Distance Between Bolt Holes	52 mm
Total Bearing Width	31 mm
Basic Dynamic Load Rating	12.7 kN
Basic Static Load Rating	6.7 kN
Limiting Speed	6 500 r/min
Housing Type	Pillow block
Number Of Bolt Holes For Fasteners	2
Fastening Bolt Hole Type	Threaded
Inner Ring Retaining Feature	Set screws
Bore Type	Cylindrical
Housing Material	Cast iron
Bearing Material	Bearing steel
Bearing Sealing	Seal and flinger on both sides
Lubricant	Grease
Note	Limiting speed with shaft tolerance h6
Product Net Weight	0.54 kg
