Schneider 2 Pole 20A Miniature Circuit Breaker (MCB) DC series – A9N61532
Product Description :
Modular Circuit Breakers - xC60. Breaking Capacity as per IEC 60947-2, Icn = 15kA, upto 40A, Higher Installation Life : Energy limitation class: 3, Tropicalization: T2 - relative humidity 95% at 55C. Higher performance by Low cost : Cascading. Increase system continuty : Discrimination. Reference Temperature of 50C as per IEC60947-2.
Product Specification:
|
Brand |
Schneider |
|
Model Name |
A9N61532 |
|
Current Rating |
20A |
|
Pole |
Two Pole |
|
Rated operational voltage |
100V - 125V DC 240V AC 50/60 Hz 380V - 415V AC 50/60 Hz |
|
Rated service breaking capacity |
6kA conforming to EN/IEC 60947-2. 100V - 125V DC 7.5kA conforming to EN/IEC 60947-2. 380V - 415V AC 50/60Hz |
|
Curve code |
C |
|
Nominal Frequency |
50Hz / 60Hz |
|
Mounting Type |
Clip-on |
|
Weight (in kg) |
0.250 |
|
Warranty |
2yr (on manufacturing defect) |
Description
Product Description :
Modular Circuit Breakers - xC60. Breaking Capacity as per IEC 60947-2, Icn = 15kA, upto 40A, Higher Installation Life : Energy limitation class: 3, Tropicalization: T2 - relative humidity 95% at 55C. Higher performance by Low cost : Cascading. Increase system continuty : Discrimination. Reference Temperature of 50C as per IEC60947-2.
Product Specification:
|
Brand |
Schneider |
|
Model Name |
A9N61532 |
|
Current Rating |
20A |
|
Pole |
Two Pole |
|
Rated operational voltage |
100V - 125V DC 240V AC 50/60 Hz 380V - 415V AC 50/60 Hz |
|
Rated service breaking capacity |
6kA conforming to EN/IEC 60947-2. 100V - 125V DC 7.5kA conforming to EN/IEC 60947-2. 380V - 415V AC 50/60Hz |
|
Curve code |
C |
|
Nominal Frequency |
50Hz / 60Hz |
|
Mounting Type |
Clip-on |
|
Weight (in kg) |
0.250 |
|
Warranty |
2yr (on manufacturing defect) |
