Rishabh Digital Multimeter RISH Multi 20

Product Description

• Convenient Triple Display

• Simultaneous measurement of voltage and frequency or voltage and min, max values is possible

• Also current and frequency or the current measurement and minimum and maximum values are displayed simultaneously The usual switching back and forth between display values is no longer necessary

• Main display resolution for AC is 4 ¾ places and for DC it is 5 ¾ places

• High Resolution & Precision

• 5 ¾ places (309,999digits) for DC measured quantities and 4 ¾ places (30,999 digits) for AC measured quantities allow for precision reference measurements and use as a calibration standard for testing devices and assemblies

• RMS Value with Distorted Waveshape

• The utilized measuring method allows for waveshape independent RMS measurement (TRMS AC)

• Additional Functions

• Resistance (Ohm), Temperature (°C), Continuity, Diode,Capacitance, Frequency, Duty cycle

• Overload Protection

• The instrument is safeguarded for up to 1000 V in all measuring functions by overload protection. An acoustic signal is generated if the upper voltage or current range limit is exceeded

• FUSE appears at the display if the fuse for the current is blown

• Measuring Category

• 1000V CAT III/600V CAT IV as per IEC Standard 61010-1

• Automatic Blocking Sockets (ABS)

• Automatic blocking sockets prevent incorrect connection of measurement cables and inadvertent selection of the wrong measured quantity

• This significantly reduces danger to the user, the instrument and the system under test and in many cases eliminates it entirely

• Backlit Display

• The instrument is provided with user selectable Back-lit for taking measurements in poor lighting conditions / dark areas

Product Specification

Brand	Rishabh
Product Type	Digital Multimeter
Product Model	RISH Multi 20
Display	5 ¾ digit
Counts	310000
Ac Voltage Range	10µV to 1000V
Dc Voltage Range	30mV-1000V
Ac Current Range	1µA-10A
Dc Current Range (amp)	1nA-10A
Capacitance Range (F)	1pF – 30000µF
Frequency Range (Hz)	0.01 Hz - 300 Khz
Operating Temperature	-10°C – 50°C
Storage Temperature	-25°C - 70°C
Relative Humidity	<75% non condensing
Altitude	2000 m
Power Input	9V
Dimensions	84X195X35 mm
Weight (g)	350 g
Warranty	As Per Manufacturer Terms And Conditions
