Product Description
-
Best Value Fanless POS Terminal
-
Crafted with functionality and flexibility in mind, PS-3616 Series features a 15.6” wide touch screen, fanless technology, and an adjustable base to scale to meet both retailers’ and consumers’ expectations all within an affordable, yet attractive and feature-rich terminal
-
Intelligently Designed
-
Equipped with an adjustable base, PS-3616 Series enables the ultimate flexibility for space-limited environments
-
Expanded Capability
-
By separating a full set of ports into the top of the terminal, PS-3616 Series provides extensive connections, easy accessibility, and reliable peripheral cabling
-
Reliable
-
Built with a 15.6” PCAP wide touchscreen display and powered by Intel Apollo Lake N3350/J3455 processors, PS-3616 Series is designed to run today’s demanding POS applications
Product Specification
| Brand | Posiflex Rugtek |
| Product Type | POS Terminal |
| Product Model | PS-3616 |
| Processor | Intel Apollo Lake N3350 |
| System Memory | DDR3L SO-DIMM x 1, max. 8GB |
| Storage Device | M.2 connector (SATA Signal Only) x 1 |
| Power Supply | 12V/40W |
| OS Support | Windows 10 IoT |
| Display & Touch | |
| LCD | 15.6" TFT LCD |
| Resolution | 1366 x 768 |
| Touch | True-flat PCAP touch with multi-touch support (IP65 on front panel) |
| I/O Expansion | |
| Serial Port | 4, DB9 x 3 + RJ50 x 1, 5V/12V support on all COM ports |
| Standard USB Port | 5, USB 3.0 x 2+ USB 2.0 x 2 (on I/O plate) + USB 2.0 x 1 (on the top) |
| PoweredUSB Port | Optional 24V x 1 + 12V x 3 via GEN8 base |
| LAN Port | 10/100/1000 Mb x 1 |
| Display Port | VGA x 1, 12V support for Posiflex monitors |
| CR Port | 1, control 2 CR via optional Y-cable, supporting 24V cash drawer |
| PS/2 Port | 1, via optional conversion cable through service window |
| Audio | Buzzer x 1; Optional internal 2W speaker x 1 |
| Expansion Slot | M.2 slot x 1 |
| Environmental | |
| Operating Condition | 0°C - 50°C, 20%RH - 90%RH (Equipped with SSD) |
| Storage Condition | -20°C - 70°C, 10%RH - 90%RH |
| Built-In Options | |
| WiFi | M.2 WiFi/BT module |
| Attachment Options | |
| POS Monitor | Non-touch TFT USB LCD: 7"/9.7" |
| Line Display | 2 x 20 rear-mount VFD customer line display; |
| Attachment | MSR; iButton; RFID; Fingerprint Sensor; Keypad |
| Physical Dimension | |
| Dimension(WxDxH) | 372 x 252.7 x 291.4 mm |
| Weight | 4.7 kg |
| Warranty | 3 Years |
