Multispan Process Indicator 4 Digit PI-38
Product Description
-
Sizes 96 X 96, 72 X 72, 48 X 48 , 48 X 96 Panel Mount
-
4+4 Digit , 7 Segment Led Display
-
2- Channel Input-Analog / Pt-100-3w
-
Up To 2 Relay
-
24v Dc Transmitter Power Supply
Product Specification
|
Brand |
Multispan |
|
Product Type |
Process Indicator |
|
Product Model |
PI-38 |
|
Digits |
4 Digit |
|
Input |
0-10V DC / 0-20mA DC/ 4-20mA DC |
|
Range |
J(0°C to 600°C), K(0°C 10 1200°C), PT-100 2Wire Or 3Wire(-99°C to 400°C,-99.9°C to 400.0°C)For Temperature Sensor, (-999 to 9999 For Analog Input) |
|
Display Resolution |
0.000/00.00/000.0/0000(Configurable,for Anlog Input) |
|
Feature |
Correction Factor, Offset, Filtaration Rate, Reverse Scaling |
|
Supply |
100 to 270V AC,50/60Hz |
|
Dimension (HxWxD) |
48 x 96 x 26 mm |
|
Panel Cutout |
46 x 92 mm |
Original: $17.53
-70%$17.53
$5.26
Description
Product Description
-
Sizes 96 X 96, 72 X 72, 48 X 48 , 48 X 96 Panel Mount
-
4+4 Digit , 7 Segment Led Display
-
2- Channel Input-Analog / Pt-100-3w
-
Up To 2 Relay
-
24v Dc Transmitter Power Supply
Product Specification
|
Brand |
Multispan |
|
Product Type |
Process Indicator |
|
Product Model |
PI-38 |
|
Digits |
4 Digit |
|
Input |
0-10V DC / 0-20mA DC/ 4-20mA DC |
|
Range |
J(0°C to 600°C), K(0°C 10 1200°C), PT-100 2Wire Or 3Wire(-99°C to 400°C,-99.9°C to 400.0°C)For Temperature Sensor, (-999 to 9999 For Analog Input) |
|
Display Resolution |
0.000/00.00/000.0/0000(Configurable,for Anlog Input) |
|
Feature |
Correction Factor, Offset, Filtaration Rate, Reverse Scaling |
|
Supply |
100 to 270V AC,50/60Hz |
|
Dimension (HxWxD) |
48 x 96 x 26 mm |
|
Panel Cutout |
46 x 92 mm |
