L&T [ Lauritz Knudsen ] MCCB Three-Pole 20 A to 100 A DN0-100D*

Product Description

• Molded case circuit breakers are a type of electrical protection device that is commonly used when load currents exceed the capabilities of miniature circuit breakers

• They are also used in applications of any current rating that require adjustable trip settings, which are not available in plug-in circuit breakers and MCBs

• Conforms to IS/IEC 60947-2

• Range: 20A to 100A

• Ics = 100% Icu*

• Suitable for Isolation

• Adjustable Over Load setting: 0.8 - 1.0 x In

• Adjustable Short Circuit setting: 6 - 10 x In**

• Microprocessor and Thermal-Magnetic based protection releases

• MCCBs for Motor backup protection

• MCCBs for Distribution and SD versions

Product Specification

Brand	L&T
Product Name	Molded Case Circuit Breaker(MCCB)
Type	DN0-100D*
Model Number | Current Rating	CM97893OOC2OG | 20 A CM97893OOD2OG | 25 A CM97893OOE2OG | 32 A CM97893OOF2OG | 40 A CM97893OOG2OG | 50 A CM97893OOH2OG | 63 A CM97893OOJ2OG | 80 A CM97893OOK2OG | 100 A
No. of Poles	3
Breaking Capacity Icu	36 kA
Rated Voltage	415 V AC
Release	Thermal-Magnetic
Impulse withstand Voltage U	8 kV
Rated Operational Voltage U (MAX)	600 V
Rated Insulation Voltage U	800 V
Utilization Category	A
Dimensions (WxDxH)	75x60x130 mm
Weight	0.73 kg
