L&T [ Lauritz Knudsen ] MCB 6A-63A B Curve Three Pole

Product Description

• True contact indication for individual pole

• Label holder facility for all configurations

• Conforms to IS / IEC 60898 and IEC 60947 - 2

• Breaking capacity of 10kA throughout the range

• Available in B, C & D curves

• Low watt loss - almost 50 % of the values prescribed by IS / IEC 60898

• Trip free mechanism

• Design based on advanced current limiting hammer trip mechanism

• No Line-Load bias

• Suitable for accessory fitment

• DC MCBs as per IEC 60947-2 Rated Voltage:130V DC (for SP), 250V DC (for DP) with breaking capacity of 6kA

Product Specification

Rating	Model
6A	BB30060B
10A	BB30100B
16A	BB30160B
20A	BB30200B
25A	BB30250B
32A	BB30320B
40A	BB30400B
50A	BB30500B
63A	BB30630B
