L&T [ Lauritz Knudsen ] MCB 0.5A-63A D Curve Single Pole

Product Description

• True contact indication for individual pole

• Label holder facility for all configurations

• Conforms to IS / IEC 60898 and IEC 60947 - 2

• Breaking capacity of 10kA throughout the range

• Available in B, C & D curves

• Low watt loss - almost 50 % of the values prescribed by IS / IEC 60898

• Trip free mechanism

• Design based on advanced current limiting hammer trip mechanism

• No Line-Load bias

• Suitable for accessory fitment

• DC MCBs as per IEC 60947-2 Rated Voltage:130V DC (for SP), 250V DC (for DP) with breaking capacity of 6kA

Product Specification

Rating	Model
0.5A	BB10E50D
1A	BB10010D
2A	BB10020D
3A	BB10030D
4A	BB10040D
6A	BB10060D
10A	BB10100D
16A	BB10160D
20A	BB10200D
25A	BB10250D
32A	BB10320D
40A	BB10400D
50A	BB10500D
63A	BB10630D
