Kusam-meco Digital Insulation Resistance Tester 3¾ Digit KM 370
Product Description
-
Digital MΩ Hitester & Digital multimeter
-
Overlod Protection
-
The meter can display actual insulation test voltage
-
LED light is used to indicate high voltage output status
-
Measures Insulation Resistance & AC & DC Voltage
-
Backlight , function characters indication
-
Auto power off
-
Low battery indication
Product Specification
|
Brand |
Kusam-meco |
|
Product Model |
KM 370 |
|
Product Type |
Resistance Tester |
|
Power |
AA 1.5V battery x 6 |
|
Test Voltage |
500V/1000V/2500V |
|
Operating Temperature |
0 °C - 40 °C, < 75%R.H. |
|
Storage Temperature |
-10 °C - 60 °C, < 80%R.H. |
|
Maximum Power Consumption |
4.5W |
|
Minimum Power Consumption |
18mW |
|
Basic Accuracy |
±(0.5%rdg + 5dgts) |
|
Display |
3¾ digit Max. 3999 Counts liquid crystal display |
|
Sampling Rate |
2 times per second |
|
Short Circuit |
1.5mA |
|
Measurement time |
½/10min |
|
Auto range |
"OL" will be displayed for overload |
|
Dimension |
170(L) x 156(W) x 64(H)mm |
|
Weight |
Approx. 650g. Including battery. |
|
Warranty |
As Per Manufacturer Terms and Condition |
Description
Product Description
-
Digital MΩ Hitester & Digital multimeter
-
Overlod Protection
-
The meter can display actual insulation test voltage
-
LED light is used to indicate high voltage output status
-
Measures Insulation Resistance & AC & DC Voltage
-
Backlight , function characters indication
-
Auto power off
-
Low battery indication
Product Specification
|
Brand |
Kusam-meco |
|
Product Model |
KM 370 |
|
Product Type |
Resistance Tester |
|
Power |
AA 1.5V battery x 6 |
|
Test Voltage |
500V/1000V/2500V |
|
Operating Temperature |
0 °C - 40 °C, < 75%R.H. |
|
Storage Temperature |
-10 °C - 60 °C, < 80%R.H. |
|
Maximum Power Consumption |
4.5W |
|
Minimum Power Consumption |
18mW |
|
Basic Accuracy |
±(0.5%rdg + 5dgts) |
|
Display |
3¾ digit Max. 3999 Counts liquid crystal display |
|
Sampling Rate |
2 times per second |
|
Short Circuit |
1.5mA |
|
Measurement time |
½/10min |
|
Auto range |
"OL" will be displayed for overload |
|
Dimension |
170(L) x 156(W) x 64(H)mm |
|
Weight |
Approx. 650g. Including battery. |
|
Warranty |
As Per Manufacturer Terms and Condition |
