C&S Residual Current Circuit Breaker 4 Pole 300mA

Product Description

• Provides Protection Against Earth Fault/ Leakage Current And Also Fullfill The Function Of Isolation

• High Short Circuit Current Withstand Capacity -6kA

• Automatically Measures And Disconnect The Circuit When Earth Fault/Leakege Current Occurs And Exceeds The Rated Sensitivity

• Equipped With Finger Protected Connection Terminals (IP20)

• Dual Termination Possible For Cable And Comb Type Busbar Connection

• Independent Of Power Supply And Line Voltage Also Free From External Voltage Fluctuation

• Incoporates A Filtering Devise For Prevention Of Nuisance Tripping Due To Transient Voltage

• Easy Padlocking Facility

• Fire Resistant Plastic Parts To Withstand Abnormal Heating And Strong Impact

Product Specification

Brand	C&S
Model	WiNtrip
Product Code | Rated Current	CSRB4P10A300 | 10 A CSRB4P16A300 | 16 A CSRB4P20A300 | 20 A CSRB4P25A300 | 25 A CSRB4P32A300 | 32 A CSRB4P40A300 | 40 A CSRB4P63A300 | 63 A CSRB4P80A300 | 80 A CSRB4P100A300 | 100 A
Color	White
Product Type	RCCB
No Of Poles	4 Pole
Earth-Leakage Sensitivity	300 mA
Voltage	415V AC
Warranty	1 Years
