Bosch Compact Ceiling Loudspeaker 6W LBD8352/10
Product Description
-
The LBD8352/10 is an economic flush-mounting ceiling loudspeaker for general purpose applications
-
It is a full range loudspeaker for speech and music reproduction in shops,department stores, schools,offices,sports halls,hotels and restaurants
-
The LBD8352/10 has a single-piece,6W loudspeaker
-
A 100 V matching transformer is mounted behind the front panel assembly
-
The moulded plastic front panel is mounted onto the loudspeaker’s metal frame,and a dust cover protects the rear
-
The appearance and colour are unobtrusive in any interior
-
Installation
-
Installation is both quick and easy,as the units have two built-in spring-loaded locking clamps that secure them into holes in the ceiling
-
Features
-
Suitable for speech and music reproduction
-
Flush-mounting in ceiling cavity
-
Easy to install
-
Simple power setting
-
Unobtrusive in virtually all interiors
Product Specification
| Brand | Bosch |
| Product Type | Ceiling Speaker |
| Product Model | LBD8352/10 |
| Electrical | |
| Maximum Power | 8W |
| Rated Power | 6W |
| Sound Pressure Level At 6 W / 1 W ( 1 KHz at 1m) | 97.5 dB / 88.5 dB (SPL) |
| Effective Frequency Range (-10 dB) | 125 Hz - 16 KHz |
| Opening Angle At 1 KHz / 4 KHz (-6 dB) | 180° / 70° |
| Rated Voltage | 100 V |
| Rated Impedance | 1667 ohm |
| Environmental | |
| Operating Temperature | -25 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Mechanics | |
| Diameter | 180 mm |
| Maximum Depth | 70 mm |
| Colour | White |
| Warranty | As Per Manufacturer Terms And Conditions |
Other Details
| Dimension (CM) LxWxH | 19.1 x 19.1 x 8.9 |
| Unit Of Measurement | 1 Piece |
| Weight | 0.600 kg |
| Generic Name | Ceiling Speakers |
| Manufacturer Details | Bosch Limited Post Box No: 3000,Hosur Road, Adugodi, Bangalore - 560030, India, Phone :18004258665 |
| Packer Details | Bosch Limited Post Box No: 3000,Hosur Road, Adugodi, Bangalore - 560030, India, Phone :18004258665 |
| Country Of Origin | India |
