BCH DC Electromagnetic Brakes One Hour Rating 13Inch SME1301

Product Description

• One Hour Rating

• During ordering, besides brake drum dia, please confirm duty rating, current rating & motor frame no

• Above current ratings are for 230 V DC Series Motors

• To convert KGM to LB.FT. multiply by 7.25

• Over the wheel design in the key to reliable performance

• Self lubricating bushings

• Features

• Limit switch attachment

• Manual release

• Residual magnetism adjustment

• *Actual product image may vary from that shown on the picture

Product Specification

Brand	BCH
Product Type	DC Electromagnetic Brakes
Product Code	SME1301
Brake Size	13 Inch
Motor Frame No(Maximum)	408,606,804
Torque(KG-M)	49.4
Maximum FLC(A)	95
Type	Series Type
Current Rating	One Hour Rating
Warranty	As Per Manufacturer Terms and Condition
