Baker Digital Internal Micrometer 150-200mm SXTD8M-BT/SXTD8i-BT

Product Description

• Bowers XTD digital internal micrometers give the operator the advantage of traditional quality ratchet gauges allied to advanced IP65 electronics

• The extended mechanical travel of the XT range means that special heads can also be manufactured to accommodate users’ most awkward measuring problems

• Measuring heads for threads, splines, slots, grooves, deep-holes and many more applications are available on request

• The Bowers XT range of internal micrometers can be supplied as individual instruments or in complete sets

• All XT instruments give the user the advantage of extended measuring travel with fixed anvils and UKAS certification of measuring head

• IP65 Electronics

• Simple 2-button operation

• Large easy-to-read display

• 3 preset memories

• RS-232 output

• Range 2 – 300 mm (0.080″ – 12″)

• 2 – 6 mm: 2 point / 6 – 300 mm: 3 point measurement

• Resolution 0.001 mm / 0.00005″

• Tungsten carbide measuring faces on all 3-point heads from 12.5mm

• Blind bore measurement from 2 mm – 6 mm and above 12.5 mm (0.500″)

• Extensions available above 6 mm for deep hole measurement

• Ratchet stop to ensure consistent measurement

• Setting rings included with individual instruments and sets

• UKAS certificates supplied as standard with all gauges

• Serial number on all digital readouts and measuring heads

• Heads with special anvils available to suit specific customer requirements e.g. threads, grooves, 2-point, spherical, splines etc

• Internal Micrometers manufactured according to DIN 863, part 4

• After sales service

Product Specification

Brand	Baker
Product Type	Digital Internal Micrometer
Part Number	SXTD8M-BT/SXTD8i-BT
Reading	0.001 mm/0.00005inch
Range	150-200 mm/6inch-8inch
Warranty	As Per Manufacturer Terms And Conditions
