Anchor UNO SPN RCBO 25A

Product Description

• Residual Current Circuit Breaker with Over Current Protection (RCBO) is a combination of MCB and RCCB, commonly used in applications where there is a need to combine protection against Overcurrent (Overload and Short-circuit) and protection against Earth Leakage currents

• RCBOs help in sensing this kind of faults and trip the circuit ensuring complete protection of the human and connected equipment

• Features

• Rated Short Circuit Breaking Capacity 10000A

• Mid Trip Indication

• Contact Position Indicator

• ISI Marking

• IP20 Protection

• Applications

• Triple protection in a single device

• Over load

• Short circuit

• Earth fault

• Suitable for domestic & residential applications

• Application on both Lighting & Motor loads

Product Specification

Brand	Anchor
Product Type	RCBO
Product Code | Current Sensitivity	98163 | 30mA 98164 | 100mA 98165 | 300mA
Series	UNO
Type	AC applications
Standard	IS 12640-2, IEC 61009-1
Current Rating	25A
No. Of Poles	2 Pole (1P +N)
Rated Voltage	240V~, 415V~
Fault Type	Type AC
Terminal Capacity	35 sq.mm
Electrical Operations	4000
Mechanical Operations	10000
Operating Temperature	-5 to 40°C
Warranty	As Per Manufacturer Terms & Conditions
