ABB Tmax Fixed Part Plug-In Four Pole

Product Description

• Fixed Part Plug-In For C.Breaker Tmax Four-Pole With Extended Front Terminals

• Number of Poles : 4

• Product Main Type : Accessories for Tmax XT

• Product Type : FP

• Rated Frequency (f) : 50 / 60 Hz

• Rated Impulse Withstand Voltage (U_imp) : 8 kV

• Rated Insulation Voltage (U_i) : 800 V

• Rated Operational Voltage : 690 V AC , 500 V DC

• Standards : IEC 60947

• Terminal Connection Type : Plug-In Circuit-Breakers , Front Extended

• Version : P

Product Specification

Product Id	Type	Suitable For
1SDA068185R1	XT1 P FP 4p EF	XT1
1SDA068190R1	XT2 P FP 4p EF	XT2
1SDA068194R1	XT3 P FP 4p EF	XT3
1SDA068198R1	XT4 P FP 4p EF	XT4
